<table cellspacing="0" cellpadding="0">
<tr>
<td width="637" class="Estilo18" u1:num="" u2:num="">DATOS TECNICOS</td>
<td width="207" class="Estilo18" u1:num="" u2:num="">GTO5040/40A</td>
<td width="207" class="Estilo18" u1:num="" u2:num="">GTO5050</td>
</tr>
<tr>
<td width="637" class="Estilo19">Cono de husillo</td>
<td width="207" class="Estilo20">MT4</td>
<td width="207" class="Estilo20">MT4</td>
</tr>
<tr>
<td width="637" class="Estilo19">Distancia del centro del husillo a la columna</td>
<td width="207" class="Estilo20">350mm</td>
<td width="207" class="Estilo20">375mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Maximo recorrido del husillo</td>
<td width="207" class="Estilo20">180mm</td>
<td width="207" class="Estilo20">230mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Rango de velocidades</td>
<td width="207" class="Estilo20">50~1450rpm</td>
<td width="207" class="Estilo20">54~2090rpm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Maxima distancia del husillo a la base de la taladradora</td>
<td width="207" class="Estilo20">1320mm</td>
<td width="207" class="Estilo20">1300mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Maxima distamcia del husillo a a la mesa</td>
<td width="207" class="Estilo20">780mm</td>
<td width="207" class="Estilo20">800mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Dimensiones de la mesa</td>
<td width="207" class="Estilo20">560x385mm/560x560mm</td>
<td width="207" class="Estilo20">600x600mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Dimensiones de la base</td>
<td width="207" class="Estilo20">730-500mm</td>
<td width="207" class="Estilo20">860x600mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Anchura del T-slot</td>
<td width="207" class="Estilo20">18mm</td>
<td width="207" class="Estilo20">18mm</td>
</tr>
<tr>
<td width="637" class="Estilo19" u1:str="Distancia entre las ranuras T-slot ">Distancia entre las ranuras T-slot </td>
<td width="207" class="Estilo20">150mm</td>
<td width="207" class="Estilo20">280mm</td>
</tr>
<tr>
<td width="637" class="Estilo19">Rango de avance</td>
<td width="207" class="Estilo20">0.1,0.2mm</td>
<td width="207" class="Estilo20">0.05, 0.1, 0.15, 0.2, 0.25, 0.3mm </td>
</tr>
<tr>
<td width="637" class="Estilo19">Motor</td>
<td width="207" class="Estilo20">0.85/1.5kW</td>
<td width="207" class="Estilo20">3.0/2.4kW</td>
</tr>
<tr>
<td width="637" class="Estilo19">Bomba</td>
<td width="207" class="Estilo20">60w</td>
<td width="207" class="Estilo20">40W</td>
</tr>
<tr>
<td width="637" class="Estilo19">Peso</td>
<td width="207" class="Estilo20">545/465kg</td>
<td width="207" class="Estilo20">920/820kg</td>
</tr>
</table>
